VERSA STRIP

/

SL-VS-4F

Façade luminaire ideal for workshop, commercial garage and warehouse environments.

Specifications

Rated Power
15/18/22/25W (2ft), 30/36/40/50W (4ft), 60/68/72/80W (8ft)
Delivered Lumen
1950/2340/2860/3250 (25W) 3900/4680/5200/6500 lm (50W) 7800/8840/9360/10400 lm (80W)
Supply Voltage
120-347V AC
IP Rating
IP20
CRI
80
Control
0-10V Dimmable
Light Source
CREE
Lamp Life
50,000 Hrs
Color Temperature
3000/4000/5000K
Projection
30º, 45º
Mounting
Ceiling, Suspended
Connection
Outdoor Rated Connections
Dimensions
609x65.02x66.55mm (25W), 1218.95x65.02x66.55mm (50W), 2437.89x65.02x66.55mm (80W)
Power Supply Details
0-10V Dimmable
Body Material
Aluminum / Polycarbonate
Body Finish
Powder Coat
Notes
Standard Power Cable: 40cm (15.75'')

Projection

30º
45º

Accessories

2ft Wire Guard

Mounting

Ceiling / Suspended / Surface

Control

Microwave Occupancy Sensor

Power Supply

Inline Connectors
Emergency Battery

Technical Files

Specification Sheet

Images

JPG
