LINEAR FIXTURE ASYMMETRIC

/

LFA-5W

Linear projector LED ideal for wall washing and grazing.

Specifications

Rated Power
5W/ft
Delivered Lumen
63lm/W (CT2000K) 64lm/W (CT2500K) 65lm/W (CT2700K) 71lm/W (CT3000K) 72lm/W (CT3500K) 73lm/W (CT4000K) 73lm/W (CT5000K)
Supply Voltage
120-227 VAC
IP Rating
IP66
CRI
95
Max Daisy Run
10ft / 3m
LED Quantity
700/m
Light Source
XICATO
Color Temperature
2200/2700/3000/3500/4000/5000K
Projection
Asymmetric
Mounting
Surface Mount
Connection
Outdoor Rated Connections
Dimensions
650x300x180 / 25.59x11.81x7.09 (20W), 1240x300x180 / 48.82x11.81x7.09 (40W), 2430x210x180 / 95.67x8.27x7.09 (80W)
Power Supply Details
0-10V Dimmable
Notes
Max Bending Radius - Rmin=20mm
Options
Fixture Length - 12inch/300mm; 24inch/600mm; 36inch/900mm; 48inch/1200mm

Projection

Asymmetrical

Accessories

Louver
Visor

Mounting

Surface Mount

Power Supply

IP Connector

Technical Files

Specification Sheet

Images

JPG
